Overview

Use this repository to submit Charts for Helm. All of them are used into APSL organitzation to deploy our Django applications over GKE.

Dependencies

Helm & Tiller

First of all you need to install the Helm client following the next instructions:

curl https://raw.githubusercontent.com/kubernetes/helm/master/scripts/get > get_helm.sh
chmod 700 get_helm.sh
./get_helm.sh

For deploys is also needed the server portion of Helm, Tiller (it talks to a remote Kubernetes cluster). To install it into the cluster, simply runs:

helm init

After the Helm 2 update, there were some changes that caused changes to the Helm package generation process for this repository and required additional software. Currently, you require install ChartMuseum following the next instructions:

curl -LO https://s3.amazonaws.com/chartmuseum/release/latest/bin/linux/amd64/chartmuseum
chmod +x ./chartmuseum
mv ./chartmuseum /usr/local/bin

For more information take a look at: Install Helm Install ChartMuseum

Packages

To use this repository as a k8s charts repository for deploy your apps you have to configure helm adding it:

helm repo add apsl https://raw.githubusercontent.com/APSL/kubernetes-charts/master/packages/

Check that it has been added.

helm repo list

NAME     	URL
stable      https://charts.helm.sh/stable
incubator	https://charts.helm.sh/incubator
apsl     	https://raw.githubusercontent.com/APSL/kubernetes-charts/master/packages/
local    	http://127.0.0.1:8879

Helm upgrade

After Helm upgrade

Structure of repository

kubernetes-charts/
├── packages/                           # Reult folder where construct temporaly packages before be installed.
|    ...
|    ├── index.yaml                     # Contains the configuration for a django app deployment.
|    ├── django-nginx-uwsgi-0.1.1.tgz   # Django package. It includes nginx, uwsgi, redis, varnish packages.
|    ├── uwsgi-0.1.1.tgz                # Uwsgi package.
|    └── varnish-0.1.0.tgz              # Varnish package.
...
├── django/                             # Contains the configuration for a django app deployment.
|    ├── .helmignore                    # List of patterns to ignore when build the package.
|    ├── Chart.yaml                     # A YAML file containing information about the chart.
|    ├── requirements.yaml              # List of required charts and their overriden configuration.
|    ├── values.yaml                    # The default configuration values for this chart
|    ├── charts/                        # Include all dependency packages
|    |                                  # IMPORTANT: No commit packages into.
|    └── templates/                     # A directory of templates that, when combined with values.
|        └── _helpers.tpl               # Difinition of template variables.
|                                       # Note that not require templates because this chart only encapsulate
|                                       # dependencies.
...
└── uwsgi/                              # Contains the configuration for a uwsgi deployment.
     ├── charts/                        # Folder that contains built packages for the dependecies of this chart.
     |                                  # IMPORTANT: No commit packages into, will be auto-generated.
     ├── .helmignore                    # List of patterns to ignore when build the package.
     ├── Chart.yaml                     # A YAML file containing information about the chart.
     ├── requirements.yaml              # List of required charts and their overriden configuration.
     ├── values.yaml                    # The default configuration values for this chart
     └── templates/                     # A directory of templates that, when combined with values.
         ├── NOTES.txt                  # A plain text file containing short usage notes (rendered with Go Template engine)
         ├── _helpers.tpl               # Definition of template variables.
         ├── deployment.yaml            # Structure of deployment for this chart.
         ├── secrets.yaml               # Base secrets for the chart.
         └── service.yaml               # Structure of service for this chart.

Take a look to The Chart File Structure to get acquainted to chart structure.

Charts information

• The django-nginx-uwsgi Chart.
• The django-celery Chart.
• The nginx Chart.
• The varnish Chart.
• The thumbor Chart.

How to

This section will try to explain you how to use this repository to deploy your applications.

How to deploy a chart over Kubernetes?

Will show you the procedure to deploy a Django application using this charts.

This example we'll deploy an app called demo, suposing you satisfy all dependencies.

1. Deploy the Django application.

helm install PACKAGE --version VERSION --namespace NAMESPACE --name RELEASE_NAME -f VALUES

• PACKAGE → The path to stored package.
• VERSION → The exact version of the package to install. If it is not set the last version will be deployed.
• NAMESPACE → The namespace that will be create on Google Cloud Platform and will be user with in the deployment.
• RELEASE_NAME → It must has a different value to namespace. It is used in the deployment and dependencies deployments.
• VALUES → Path to the file where are all values that overrides the Helm chart, for example SECRET_KEY or DATABASE_PASSWORD, etc.

helm install apsl/django-nginx-uwsgi --version 0.1.1 --namespace demo --name r-demo -f your_demo_app_values.yaml

How to test your deployment before apply it on your K8s cluster?

Helm Template is a plugin used to render the resultant deployment of your chart.

1. Install:

helm plugin install https://github.com/technosophos/helm-template

2. Use it:

helm template -n NAMESPACE -r RELEASE_NAME -f VALUES --notes CHART > output.yaml

• NAMESPACE → The namespace used with in deployment.
• RELEASE_NAME → The release name used with in deployment.
• VALUES → Override specific values for application.
• CHART → Location path to the chart.

helm template -n demo -r r-demo -f your_demo_app_values.yaml --notes . > ~/k8s-deployment.yaml

Structure example of data values

This section show you how structure the values to deploy a single application using django-nginx-uwsgi chart.

# your_demo_app_values.yaml
global:
  image:
    uwsgi: eu.gcr.io/project/my-app-uwsgi
    nginx: eu.gcr.io/project/my-app-nginx

  dataConfigMap:
    - name: REDIS_HOST
      value: "10.0.0.1"
    - name: DEFAULT_FROM_EMAIL
      key: django.emailDefaultFromEmail
      value: Demo <[email protected]>
    - name: AWS_STORAGE_BUCKET_NAME
      value: my-app-prod
    - name: AWS_ACCESS_KEY_ID
      value: aws-key-id

  dataSecrets:
    - name: AWS_SECRET_ACCESS_KEY
      value: secret-aws-access-ley

app:
  deployment:
    probes:
      livenessEnabled: true
      liveness:
        enabled: false

  replicaCount: 1

  strategy:
    rollingUpdate:
      maxSurge: 1
      maxUnavailable: 0
    type: RollingUpdate

  secrets:
    secretKey: django-secret-key-value
    passwordDB: django-passwd-db-value
    sentryDSN: sentry-dsn-value

  configMap:
    enableSentry: "True"
    databaseHost: 127.0.0.1
    databaseName: myappdb
    databasePort: "5432"
    databaseUser: usrmyapp
    enableBasicAuth: "False"
    enableHttpsRedirect: "True"
    enable3wRedirect: "True"

varnish:
  enabled: true

crons:
  enabled: false

redis:
  enabled: false

Contributors

Developing new Helm charts

There are some notes and some command line instructions that can be useful as a guide how to develop new charts.

To create a new chart:

helm create CHART

• CART → Full path to destination chart.

helm create django-nginx-uwsgi

After develop your template chart, you can validate if your chart is valid running a lint.

helm lint django-nginx-uwsgi

Building package

If you contribute creating new Charts or improving the existent you should do this:

• Serve your packages locally
• Resolve repository dependencies (local repository)
• Update dependent locally repositories your Chart
• Generate your package
• Regenerate index-yaml

To simplify all this tasks, you only have to execute this:

make helm-up & \
make helm-packages && \
helm repo index packages

NOTE: Its possible see some non-liveness message using make command to build packages. If the message is like "No requirements found in ~/kubernetes-charts/nginx-uwsgi/charts" ignore it. It is because the commnand script try to get dependencies of all packages even if it has not charts (the dependency folder).

Use case:

We will generate a new chart packagedemo:

0. Create the chart

helm create packagedemo

1. Serve built local packages:

cd packages
helm serve

2. Build all dependent packages:

helm package -u -d packages uwsgi
helm package -u -d packages nginx
helm package -u -d packages packagedemo

or use the Makefile commands:

make helm-packages

3. Generate index

helm repo index packages

or use the Makefile commands:

make helm-index

4. Test to show resultant yaml for deployment:

helm template packages/packagedemo-0.0.1.tgz -n demo -r r-demo -f your_demo_app_values.yaml --notes . > ~/k8s-deployment.yaml

or

helm template ./django-nginx-uwsgi
